Product Description
Hoefer SUB6 Mini Submarine Gel Electrophoresis Unit
Ideal for routine preparatory and analytical electrophoresis techniques
The SUB6 Mini Horizontal Gel Unit is ideal for routine nucleic acid preparatory and analytical electrophoresis techniques. It has a maximum 32-sample throughput capacity and features a removable gel-casting tray with end gaskets that allow gels to be cast directly within the tank.
Features and Benefits:
- Color-coded and height adjustable combs—easily identify comb thickness at a glance and control well depth
- Colored loading strips—for easy well detection when loading
- Compact tank—reduces the buffer volume required to cover the gel, providing greater control over the voltage gradient and run-time
- UV-transparent running tray—allows the user to image the gel without risk of damage due to handling
- Side handles—for safe and easy transportation around the laboratory
Includes:
- Buffer Chamber Assembly
- Safety Lid
- High Voltage Leads
- Running Tray with Silicone Gasket*
- 1 mm thick, 8-well combs, 2 pcs
- Colored Loading Strips
- The included running tray is lined with silicone gaskets which form a leak-proof seal against the inner walls of the running chamber when the running tray is turned 90° to the direction of electrophoresis.
Specifications:
| Gel Dimensions (W x L) | 6 x 7.5 cm |
| Maximum Buffer Volume | 325 ml |
| Maximum Power Settings | 300 V, 200 mA, 60 W |
| Maximum Sample Capacity | 32 |
| Maximum Running Temperature | 45°C |
| Indoor Use | 4 to 40°C |
| Humidity | Up to 80% |
| Unit Dimensions (W x L x H) | 13 x 24 x 6.5 cm |
| Unit Weight | 1.50 kg |
- Effective immediately, SUB Series tanks are available in green and gray, in addition to our standard Hoefer red.
- This change is cosmetic only—the tank design, structural components, included accessories, and performance remain exactly the same.
- Please note that SUB units will be shipped in a randomly selected color. We appreciate your understanding and continued support.
