Product Description
UV Tissue Cassette Printer w/ 10" Touch Screen and Built-In Scanner
Cassette Printer: UV Laser technology for quick, consumable-free printing. 10-inch touchscreen, 6 loading hoppers (total 600 cassettes). Prints in <3 seconds, individual or batch dispensing. Built-in scanner, customizable templates. Connects to LIMS/HMIS.
The UVP201001, Ultraviolet Laser Microscope Slide Printer, and the UVP202001, Ultraviolet Tissue Cassette Printer, represent the next generation of slide printers. These advanced and easy to use printers can print directly on slides or tissue cassettes without using ink or printer consumables. The ultra-fast laser can print text, symbols, and barcodes on slides or cassettes in under three seconds. The large 10-inch color touch screen allows for configuration of the print template and easy data entry. All Four E’s USA’s printers are LIMS and HIMS compatible for easy integration.
| Type | Tissue Cassette Printer |
| Model | UVP202001 |
| Pinter Type | Long Life UV Laser |
| Capacity | 600 Cassettes (6 x 100 Cassette Hoppers) |
| Removable Hopper | Yes, 6 Hoppers |
| Printing Capabilities | Text, Symbols, Barcodes, QR Code Multiple formats of Linear and 2D Barcodes |
| Print Speed and Consumables | < 3 seconds, no consumables required |
| Interface and Connections | 10” Color Touch Screen, 2 x Ethernet, 4 x USB, 1 x VGAConnection Types 1 x COM, 1 x HDMI, Built-in Barcode Scanner |
| Output Storage Solutions | Single, Small Batch, Large Batch |
| LIMS/HIMS Compatible | Yes, all systems |
| Operation Modes | Standalone, Batch Printing Software, Connected to Cassette Printer, LIMS/HIMS Controlled |
| Warranty | 2 years |
