SHIPS VIA FREIGHT (charges apply). Built-to-order, ships in ~6 weeks from order placement.
The turbo blower-assisted forced airflow design coupled with a heavy-duty blower motor offers excellent temperature uniformity and fast recovery times. Airflow is directed evenly across all shelves and samples to ensure consistent drying, curing, and baking results.
The SMO large capacity units are perfect for high volume sample and drying applications, including production processes. These units are especially ideal for glassware drying.
These SHEL LAB ovens Feature:
- Three-inch Adjustable Exhaust Port
- Stainless Steel Shelves
- Independent Overtemperature Safety
- High-Temperature Silicone Door Seal
- No Exposed Heating Elements
- Added docking collars to intake and exhaust ports to allow ducting to be attached for venting exhaust out of the workspace
- Shelf standards moved to the sides of the unit for easier shelf installation
- Wrap Around Insulation
- Durable Powder Coat Paint Exterior Finish
- Digital Timer
- 24 Month Limited Warranty
EXTERIOR DIMENSIONS (W × D × H)
39.1 × 35 × 78.3
(993 mm × 889 mm × 1989 mm)
INTERIOR DIMENSIONS (W × D × H)
30.8 × 25 × 61
(782 mm × 635 mm × 1575 mm)
VOLUME
27.6 cu.ft. (781 L)
SHELF DIMENSIONS (W × D)
30.1 × 24 (765 mm × 610 mm)
UNIT WEIGHT
390.0 lbs (177.3 kg)
INTERIOR METAL
430 SST
EXTERIOR METAL
Painted Cold Roll Steel
OPERATING TEMPERATURE RANGE
Amb +15C - 260C
TEMPERATURE UNIFORMITY - MIDRANGE
3 °C
TEMPERATURE STABILITY - MIDRANGE
0.4 °C
CONTROLLER TYPE
Digital
DISPLAY RESOLUTION
1 °C
POWER VOLTAGE , FREQUENCY AND CURRENT
230 VAC, 50/60 Hz, 20.0 Amps
SAFETY CERTIFICATIONS
UL 61010-1, EN 61010-1, CSA 61010-1, CE
