NAE100132 is a high-throughput nucleic acid extractor that uses magnetic bead technology to purify DNA and RNA from a wide range of sample types. The system features a user-friendly interface that allows for easy programming of extraction parameters and the ability to process up to 32 samples in a single run. With its advanced magnetic bead technology and multiple heating modules with individual heating controls, the NAE100132 delivers high yields of pure nucleic acid with minimal hands-on time, reducing the risk of contamination and ensuring reliable results. The system is suitable for use in both research and clinical settings, making it an ideal solution for high-throughput nucleic acid extraction needs.
32-well. Automated processing for efficient and error-free operations. Touchscreen, UV disinfection, advanced stirring, and individual heating modules ensure safe, reliable, and contamination-free nucleic acid extraction.
| Volume Capacity | 30-1000μl |
| Sample Quantities | 1-32 |
| Plate Quantity | 2 |
| Plate Type | 96-well deep-well plate |
| Processing Time | 20min-40min/run (depending on reagent types/volumes) |
| Reagent Type | Magnetic bead-based open-source reagents |
| Heating Temp | Room Temp.~ 100℃ |
| Mixing Intensities | Adjustable | 5 Levels |
| Magnetic Bead Recovery Rate | 96% |
| Inter-well Purification Variation | CV＜5% |
| Working Noise | ＜50dB |
| Exhaust | Fan |
| Data Storage Capacity | ＞500 programs |
| Program Management | Create, Edit, and Delete options available |
